LED Acrylic Signs

LED Acrylic Signs sample case

LED acrylic signs benefits

LED acrylic signs details

Signs Shell

Could be 3D fabricated metal signs shell, 304 stainless steel by default, or 3D fabricated acrylic signs shell or 3D CNC engraved solid acrylic signs shell.

Finishes

Light transmitting surface will add vinyl on the surface in order to control lighting color.

Stainless steel signs shell surface could be mirror polished, brushed, painted/powder coated in color or plated.

Acrylic signs shell surface would be painted/powder coated in color or just use the black acrylic.

LED lights

LED modules or LED strips are usually used, and PCB LEDs can be used for mass products.

Light color

Could use white, warm white, blue, green, red, yellow, pink, purple or use the full color RGB.

Lighting direction

Front-lit, the front surface of the signage is illuminated

Side-lit, the border of the signage is illuminated

Backlit-lit, the back-panel of the signage is illuminated

Double-sided-lit, the front surface and the back-panel of the signage are illuminated

Whole-lit, the front surface and the border of the signage are illuminated, the back-panel could be illuminated too

Installation

Use stuld bolts to fix on the backing wall by default.

LED acrylic signs FAQ

How to determine the right LED acrylic signs size?

In our experience, there is a roughly proportional relationship between the height of the LED acrylic signs and the best visible distances , generally 10 to 12 times. For example, a 10 inches LED acrylic signs can be distinguished well from a distance of about 100 inches to 120 inches. So choose a fittest visible distances based on your request, then you will know how height your signs should be.

What’s the best fonts for LED acrylic signs border?

In fact for us, we care more about the minimum stroke width than the font. We need the minimum width of the strokes reach 10mm(0.39″), else we will have not enough space to place the LED in the signs shell, and if it is too small we even can not produce the 3D signs shell.
As long as the above requirements are met, in fact you can choose the font you need according to your personal preferences.
If you prioritize readability, then sans serif fonts that are thick like Helvetica or Arial will maximize your LED acrylic signs’ visibility. Many contemporary and modern backlit signs are designed to be highly visible.
If you need your signs have some special style, then you can see the scrip fonts, thin, decorative font styles, and serif-style fonts, though they might difficult to read or see from a distance, they have rich style.
BTW, the spacing of LED acrylic signs is crucial for readability. Designers call the spacing as “kerning”. Too big or too close kerning all will create visibility issues.

Should I choose the customize LED acrylic signs?

What we always recommend is to have customized LED acrylic signs. In this way, you will have the chance to adjust the font type and size to ensure the signs you mount are the ones that customers admire year after year. Only the customize LED acrylic signs is really fit you, from the fonts, size, finishes, to lighting color, our high quality custom LED acrylic signs will be a part of your business well.

Can the LED acrylic signs board be used outdoor?

The LED acrylic signs can be used outdoor very well, don’t worry.
Generally speaking, acrylic can be used for more than 8 years in an indoor environment, and can be used for about 5 years outdoors due to the ultraviolet rays.
And for the LED lighting source, we will use the IP67 LED for the LED acrylic signs. If your area has rainy season or often has heavy rain, we will add leak holes to your LED acrylic signs to improve the service life.
